Motion Sensor

MAKE YOURSELF FEEL SAFE - THE ULTIMATE PROTECTION!

Motion Sensor is a vital device when it comes to best in class security. With PIR and microwave sensor, this motion sensor is built with the latest technology and would provide you with the protec-tion you want. Motion sensors do not only provide safety to the user, but it also provides conve-nience to the user. With the detection of the motion, the lights will automatically light up and pro-vide safe access to the house or the building.

There are two types of motion sensors:

PIR

PIR motion sensor has the technology to detect living being with its thermal sensors. The heat pro-duced by a human being or animals helps the PIR motion sensor in catching them. It can identify day & night and adjusts the LUX accordingly. This type of sensor is usually used in small areas such as a narrow hallway, front or back porch and other smaller spaces.

MICROWAVE

This type of sensor is highly sensitive as it has the technology to detect leaves & trees blowing with the wind. This type of sensor is usually used in large spaces such as an auditorium, driveway, garden, open office spaces and other oddly shaped and open areas. This device is built with an inte-grated circuit and with high-frequency electro-magnetic waves (5.8GHz) and can detect through doors, glass and through thin walls.

FEATURES
  • A device with a quick, easy and hassle-free installation process.
  • When motion is detected, the sensor switches on the light for the user.
  • The device can work with 3LUX ambient (3 being the minimum), an the light sensitivity can be adjusted according to the day and night light.
  • Designed in a retrofit manner to be installed within minutes.
  • Robust design for long-lasting performance.
  • Adjustable delay while switching off the light.
  • Adjustable sensing range.
APPLICATION

RESIDENTIAL AREAS

CORPORATE OFFICES

INDUSTRIAL WAREHOUSES AND FACTORIES

TECHNICAL SPECIFICATIONS

PIR SENSOR

  • Power Source: 110-240V/AC
  • Power Frequency: 50/60Hz
  • Ambient Light: <3 - 2000LUX (adjustable)
  • Rated Load: 100W - 400W
  • Detection Range: 360°
  • Time Delay: Min.- 1 Osec ± 3sec; Max. - 7min ± 2min
  • Detection Distance: 8m max(<24°C)
  • Working Temperature: -20-+40°C
  • Working Humidity: <93%RH
  • Power Consumption: approx 0.5W
  • Installation Height: 2.2-4m
  • Detection Moving Speed: 0.6-1.5nn/s

MICROWAVE SENSOR

  • Power Source: 220-240V/AC
  • Power Frequency: 50/60Hz
  • Ambient Light: <3 - 2000LUX (adjustable)
  • Rated Load: 300W - 800W
  • Detection Range: 360°
  • Time Delay: Min.- 1 Osec ± 3sec; Max. - 1 2min ± 1 min
  • Detection Distance: 1-8m (radius), adjustable
  • HF system: 5.8 GHz CW radar, ISM band
  • Transmission Power: <0.2mW
  • Installation height: 2-6m
  • Power Consumption: approx 0.9W
  • Detection Moving Speed: 0.6-1.5m/s

The motions sensors doest not only provide a safe pathway to the user; it also helps in detecting robbers and burglars, and the sensor detects any movement. If the lights are on, that means some motion was detected. Therefore, in the case of suspicious activity, the sensor reacts to the movement and lights up, alerting the user.

For queries or more information on Motion Sensors, you can contact us at info@inovic.co.in
